290XL-6-LED

I/O PortsUSB3.0 x 1
USB1.1 x 2
HD Audio & Mic
Reset Button
Power Button
Material0.6mm Steel Structure
Tempered Glass
Plastic
Left Side PanelTG with 4 Screws
Right Side PanelSteel with Mesh
Motherboard SupportATX/ M-ATX/ ITX
PSU SupportATX Bottom mounted (140-180mm)
Fan Support120mm x 3 at MBO Bracket
120mm x 3 at Top
120mm x 1 at Rear
120mm x 2 at PSU Cover
Radiator Support240mm at MBO Bracket
360mm at Top
120mm at Rear
Drive Support3.5″ HDD x 2
2.5″ SSD x 2
PCI Expansion Slotsx 7+2
Max VGA Length400mm
Max CPU Height168mm
Cable Management24mm
Dust Filter Top, Bottom
Structure Dimension420(L) x 210(W) x 465(H)mm
Carton Dimension
Packaging StandardK=A+EPS & Brown Carton
