i931-M

Strucuture Size415 x 210 x 470mm(L x W x H)
Case  Size455 x 210 x 485mm(L x W x H)(with feet)
Packing size532(L)*262(W)*515(H)
I/OUSB3.0 x1+USB1.0 x2, HD Audio, Power button+reset button
Left Side PanelTempered Glass with 4 Screws
Right Side PanelMetal
MaterialSPCC 0.6mm Black
PSU Position & TypeBottom & ATX PSU (150-245mm)
MBO SupportEATX/ATX/ MATX/ Mini-ITX
Drive Bays3.5''HDD x 2
2.5''SSD x 2 TOOLESS
Cooler Fan Support3 x 120mm on Front
2 x 120mm MBO bracket
3 x 120mm on Top
1 x 120mm on Rear
2x 120mm on power cover
Water Cooling SupportFront:  120/240/280/360mm
Rear:120mm
Top:120/240/280/360mm
Motherboard: 120/240mm
PCI Expansion Slotsx 7
Max VGA Card Length400mm
Max CPU Cooler Height168mm
Cable Management25mm
Magnetic Dust Filter On Top & Bottom
Packaging StandardK=A+EPS & Brown Carton Box
QTY900PCS
